Description
IN-Series X-ray Generator:
Maximum mA: 1000 (adjustable for each focal spot)
kW rating: 32 – 100 kW
kVp range: Radiography 40 to 150 kV / Fluoroscopy 40 to 125 kV
mAs Range:Tube dependent, max 1000 mAs
Power supply:
24 VDC, 4 amp
120 VAC, 2.5 amp
240 VAC, 1.5 amp
Available configurations:
Radiography:
-10 to 320 mA (30 kW)
-10 to 400 mA (32 kW)
-10 to 500 mA (40 kW)
-10 to 630 mA (50 kW)
-10 to 800 mA (65 kW)
-10 to 1000 mA (80 and 100 kW)
Fluoroscopy:
-0.5 to 10 mA
-0.5 to 20 mA
Options:
-Optional AEC, up to four inputs
-Optional ABS with kV or kV/mA fluoro stablilizer
-Optional remote fluoro control box for tabletop use or SFD mounting
-Optional Dose-Area Product (DAP) display.
