V-MAX Pro Series C-Arm Table

Surgical Tables

The V-MAX Pro Series Vascular C-Arm Tables by Surgical Tables, Inc. are designed to deliver exceptional quality, reliability, and ease of use for medical professionals. These tables feature advanced functionality, including height adjustment and four-way float capabilities. For added versatility, the V-MAXT model includes Trendelenburg positioning, making it ideal for a wide range of vascular procedures.

Equipped with a responsive electric brake system, the V-MAX Series ensures seamless operation of the four-way float mechanism. The tabletop glides effortlessly during adjustments and locks securely in place upon releasing the control. A user-friendly joystick, designed for precision and comfort, can be positioned anywhere along the table’s imaging area, providing ultimate flexibility for practitioners working from any angle.

With the V-MAX Pro Series, your practice benefits from a combination of innovation and practicality to support vascular imaging and procedures efficiently.

Category:

Description

Standard features for both table models include:

  • Diving board style for easy C-arm access
  • Large patient capacity (500-lb pound load)
  • 2” high quality patient comfort pad
  • Facial cut-out access
  • A 24” wide carbon fiber top eliminates the needs for arm boards
  • A 27″ wide top upgrade is also available
  • An 84″ length to accommodate even the tallest of patients
  • Easy patient transfer to table
  • Any OR accessory can be rigidly attached to the table top
  • Bellows to cover and protect the table motor assembly
  • Rotating and lockable casters
  • Control handle (joystick) for easy table movement

Options include:

  • Foot switch
  • Modular side rail system
  • Surgical arm boards (can rotate 180 degrees)
  • Procedural arm boards (each can rotate 180 degrees)
  • Rectangle arm boards
  • Lollipop arm boards
  • Catheter Tray



V-MAX Series Models

The V-MAX and V-MAX T models differ in heights and movements supported:

  • V-MAX offers Height (28″ to 38″), Lateral Float (14″), and also Longitudinal Float (38″, +/- 19″) adjustments.
  • V-MAX T offers Height (30″ to 40″), Lateral Float (14″), Longitudinal Float (38″, +/- 19″), and also Trendelenburg (+/- 17°) adjustments.

A Joystick is standard with both V-MAX models.

The height buttons support raising and lowering the table top. The Trendelenburg buttons control the angle of inclination of the head end. The four-way float allows to user to move laterally and longitudinally with the press of one button at the top of the joystick.

Note that all V-MAX Series imaging tables with motorized movements require 120 VAC power for operation
