Fujifilm ASPIRE Cristalle

Fujifilm

ASPIRE Cristalle with Digital Breast Tomosynthesis (DBT) is built smarter because it is built with insight into image quality, operational excellence, and a better patient experience.

Brochure

Description

Digital Breast Tomosynthesis (DBT)

​

Radiologists using ASPIRE Cristalle with DBT will realize valuable, enhanced clinical efficacy compared to using full-field digital mammography (FFDM) alone.

​

  • DBT acquires a series of low-dose images at different angles. The acquired images are reconstructed into a series of high-resolution slices displayed individually or dynamically in a cine mode.

  • The reconstructed tomographic images make it easier to identify lesions that might otherwise be difficult to visualize in traditional 2D mammogram images because of the presence of overlapping breast structures.

  • Superior diagnostic accuracy and superior (lower) recall rates for non-cancer cases are possible with ASPIRE Cristalle’s DBT technology.

​

Hexagonal Close Pattern (HCP) Direct Conversion Technology

​

  • 50-micron image display

  • Reduced acquisition time — only 15 seconds

  • Hexagonal pixels distribute the electrical field more efficiently than traditional square pixels, to capture stronger signals with less noise

  • The resulting images have high DQE and MTF, producing brilliant image quality

  • Offers exceptionally sharp images, even at a low dose

​

iAEC plus ISC: Optimized x-ray dose and contrast for each breast type

​

Fujifilm’s proprietary technology makes it possible to lower the dose while offering optimized contrast, even in dense breasts and implants.

​

  • Intelligent AEC (iAEC) “factors in” breast composition to calculate the optimal dose and exposure techniques for each examination. iAEC enables a more accurate calculation of exposure parameters than is possible with conventional AEC systems.

  • iAEC can also greatly speed workflow for exams of implanted breasts by automatically calculating the optimal exposure.

  • Fujifilm’s Image-based Spectrum Conversion (ISC) technology optimizes contrast in an image, offering the dose advantages of a tungsten target for all exposures and breast types.

​

Patented Comfort Paddle designed to improve patient comfort during mammograms

The unique Comfort Paddle allows pressure to be more evenly and gently distributed across the breast compared to conventional, flexible paddles.

​

  • Slotted paddle edge allows the plate to flex to the contour of the breast

  • Bends from the center of the breast to thinner edges

  • Distributes pressure more evenly

  • Tilting paddle allows for more gradual and more even compression

  • Available in two sizes to accommodate different breast sizes: 18x24cm and 24x30cm

  • Available standard on ASPIRE Cristalle, optional on ASPIRE HD Plus

Learn more about the Comfort Paddle and other accessories here.
